The BoundVis B256A1 Infrared Camera Module is a compact, high-performance 640×512 thermal imaging camera module engineered for demanding industrial and commercial applications. Featuring a 12 μm uncooled VOx detector, ≤40mK NETD, and a 60Hz frame rate, it captures crisp thermal images with exceptional sensitivity and smooth real-time performance. Equipped with a 9 mm lens and CVBS (PAL) analog video output, the B256A1 delivers long-range thermal detection up to 900 meters, making it ideal for security surveillance, industrial inspection, UAV payloads, robotics, firefighting, and intelligent monitoring systems. With low power consumption, a compact footprint, and reliable UART control, it offers seamless integration into a wide range of OEM thermal imaging solutions.
Key Features of B256A1 Infrared Camera Module | CVBS/USB/UVC 12μm Thermal Imaging Camera Core
640×512 High-Resolution Thermal Imaging
Powered by a 640 × 512 effective FPA uncooled VOx detector with a 12 μm pixel pitch, the B256A1 captures highly detailed thermal images, enabling accurate target observation and temperature-based monitoring in demanding environments.
Excellent Thermal Sensitivity (≤40mK NETD)
With a NETD of ≤40mK, the module detects subtle temperature differences, producing sharper thermal contrast and improved image clarity even in low-contrast or challenging weather conditions.
Smooth 60Hz Real-Time Video
A 60Hz frame rate delivers fluid thermal video with minimal motion blur, making the module ideal for tracking moving targets in surveillance, robotics, UAV navigation, and industrial automation.
Long-Range Target Detection
Equipped with a 9 mm infrared lens and a 46.2° × 37.7° field of view, the B256A1 provides:
- Detection Distance: Up to 900 m
- Recognition Distance: Up to 225 m
- Identification Distance: Up to 113 m
This makes it suitable for perimeter protection, border surveillance, infrastructure monitoring, and outdoor security applications.
Easy Integration with CVBS Video Output
The module supports CVBS (PAL format) analog video output, allowing direct compatibility with DVRs, industrial displays, embedded systems, and traditional surveillance equipment without complex hardware modifications.
Flexible Image Optimization
To meet different application requirements, the B256A1 supports:
- White Hot & Black Hot display modes
- Adjustable image enhancement
- Adjustable brightness and contrast
- 1×–8× digital zoom
These features improve image visibility and target recognition under varying operating conditions.
UART Intelligent Control
The integrated UART interface (115200 baud) enables convenient control of image parameters, shutter operation, lid calibration, and Non-Uniformity Correction (NUC), simplifying system integration and remote device management.
Low Power, High Reliability
Operating at ≤0.8W, the module is optimized for energy-efficient embedded systems while supporting a 5V–18V DC power input for flexible installation across industrial platforms.
Industrial-Grade Durability
Designed for harsh operating environments, the B256A1 offers:
- Operating Temperature: -20°C to +60°C
- Shock Resistance: 80g @ 4ms
- Weight: 24.5 g
- Compact Dimensions: 21 × 21 × 33.8 mm
Its robust design ensures dependable performance in mobile, outdoor, and industrial applications.
Applications
The BoundVis B256A1 is suitable for a wide range of thermal imaging applications, including:
- Security & Perimeter Surveillance
- Industrial Inspection & Predictive Maintenance
- UAV & Drone Thermal Payloads
- Robotics & Autonomous Systems
- Smart Building Monitoring
- Fire Detection & Firefighting
- Electrical & Mechanical Inspection
- Intelligent Transportation Systems
- Outdoor Thermal Monitoring
- OEM Thermal Imaging Devices
Contact BoundVis today to request technical documentation, pricing, product samples, or customized thermal imaging solutions. Our engineering team is ready to support your next innovation in infrared vision technology.
